Multi-section hydraulic jack

The double-acting large-tonnage jack has large output force, light weight, and strong carrying capacity.

The feature of long-distance operation in any space position, equipped with the company's electric high-pressure pump station,Can be realized: various forms of work such as pushing, pushing, pulling, squeezing, pressing, etc.

  • Features

Widely used in transportation, railways, bridges, shipbuilding, construction,Equipment jacking installation, commissioning, maintenance, underground pipe jacking and other operations for industrial and mining enterprises.


  • Parameters

Model

Tonnage

Stroke

Oil storage

Configure pump

Body height

Stretch height

Outer diameter

Inner diameter

of tubing

Weight

YLDG-10270D

10

O

270

810

HHB-700A

250

520

110

45

18

T

135

385

75

18

YLDG-10435D

10

O

435

2250

280

715

153

45

40

T

290

570

75

40

S

145

425

105

40

YLDG-15300D

15

O

300

1308

280

580

125

52

28

T

150

430

85

28

YLDG-15510D

15

O

510

3543

HHB-630A

320

830

175

52

60

T

340

660

85

60

S

170

490

120

60

YLDG-30300D

30

O

300

2088

HHB-700A

304

604

152

75

45

T

150

454

105

45

YLDG-30600D

30

O

600

6803

HHB-630A

366

966

220

75

106

T

400

766

105

106

S

200

566

160

106

YLDG-50300D

50

O

300

3800

350

650

170

95

68

T

150

500

135

68

YLDG-50600D

50

O

600

9500

390

990

230

92

152

T

400

790

135

152

S

200

590

185

152




  • Programme


Two-way hydraulic electric set

Features: The double-acting large-tonnage jack has large output force, light weight, strong carrying capacity, and can be operated remotely in any space position

Uses: used in transportation, railways, bridges, shipbuilding, construction, mining and other industries





Multi-section hydraulic electric set

Features: The double-acting large-tonnage jack has large output force, light weight, strong carrying capacity, and can be operated remotely in any space position

Uses: used in transportation, railways, bridges, shipbuilding, construction, mining and other industries


Multi-section self-locking different synchronization

(two synchronization + three synchronization control separately) set

Features: light weight, strong carrying capacity, long-distance operation in any space position

Uses: used in transportation, railways, bridges, shipbuilding, construction, mining and other industries
