Double-acting self-locking hydraulic jack

The built-in protection valve can prevent the return pressure of the piston rod from being too high.

The dustproof ring design can reduce pollution and extend the service life.

The standard hard deep groove saddle can be tilted to adapt to uneven components.Optional tube or plate hydraulic one-way valve or one-way throttle valve to ensure the lifting and lowering process.


  • Features

Can be used for long-term support occasions.


  • Parameters


Model

Tonnage

Stroke

Body height

Stretch height

Outer diameter of cylinder

Piston rod diameter

Inner diameter of cylinder

Weight

DYZ50-100

50

100

225

325

127

70

100

35

DYZ50-200

200

325

525

46

DYZ50-300

300

425

725

48

DYZ50-500

500

625

1125

63

DYZ100-100

100

100

250

350

180

100

140

58

DYZ100-200

200

350

550

78

DYZ100-300

300

450

750

96

DYZ100-500

500

650

1150

130

DYZ150-100

150

100

260

360

219

125

180

58

DYZ150-200

200

360

560

86

DYZ150-300

300

460

760

103

DYZ150-500

500

660

1160

255

DYZ200-100

200

100

285

385

240

150

200

96

DYZ200-200

200

385

585

116

DYZ200-300

300

485

785

161

DYZ200-500

500

685

1185

221

DYZ320-100

320

100

310

410

330

180

250

196

DYZ320-200

200

410

610

258

DYZ320-300

300

510

810

311

DYZ320-500

500

710

1210

456

DYZ400-100

400

100

355

455

380

200

290

198

DYZ400-200

200

460

660

264

DYZ400-300

300

555

855

367

DYZ400-500

500

755

1255

456

DYZ500-100

500

100

360

460

430

200

320

323

DYZ500-200

200

460

660

420

DYZ500-300

300

560

860

581

DYZ500-500

500

760

1260

599
